20ft DNV Offshore-Rated Containers

This 20ft DNV Offshore-Rated Container is built for secure transport and storage in marine environments. Certified to DNV 2.7-1 standards, it is constructed for use on fixed and floating offshore installations.

Key Features

• DNV 2.7-1 certification: Designed, built, and certified to the rigorous requirements of DNV 2.7-1, the internationally authoritative standard for offshore containers.
• High-strength construction: Made from corrosion-resistant steel to withstand harsh weather, salt spray, and the dynamic forces of maritime transport.
• Certified lifting gear: Supplied with DNV-certified lifting slings for safe, compliant handling in offshore lifting operations.
• Stackable design: Engineered for secure stacking, even with lifting slings attached, to optimize deck space during transport or storage.
• CSC plated: Complies with the International Convention for Safe Containers (CSC) for international transport.

This 20ft Offshore-Rated Container is a portable unit purpose-built for the repeated transport of goods and equipment to, from, or between offshore installations. Its primary use is in the oil and gas industry and on offshore wind farms, where equipment must endure significant operational demands.

Structural integrity is verified through a comprehensive DNV certification process covering a detailed design evaluation, a production process audit, and a final prototype inspection. High-strength steel is used for the main structure, with materials chosen to prevent brittle fracture and resist corrosion.

Corner castings and lifting points are reinforced and arranged to handle the specific mechanical stresses of lifts at sea. The design accounts for all critical transport phases, including delivery from shore, on-board securing, and dynamic lifting. Units manufactured after 2018 are designed, built, and certified to meet DNV 2.7-1 together with ISO 10855-1.

Internal lashing points come standard, allowing various cargo types to be secured within the container. The robust, proven design delivers reliable performance and longevity in demanding settings.

Technical Specifications

• External nominal dimensions (L x W x H): 20' x 8' x 8'6" (6.06 m x 2.43 m x 2.59 m)
• Internal dimensions (L x W x H): approx. 19'3" x 7'7" x 7'3" (approx. 5.89 m x 2.33 m x 2.21 m)
• Internal cubic capacity: approx. 1,080 ft³ (approx. 30.6 m³)
• Maximum gross weight (offshore): 44,090 lbs (20,000 kg)
• Tare weight: approx. 8,490 lbs (approx. 3,850 kg)
• Max payload (offshore): approx. 35,600 lbs (approx. 16,150 kg)
• Classification: DNV 2.7-1 / ISO 10855-1 (post-2018)

Note: Specifications are based on standard 20ft DNV container configurations and may vary. Always refer to the container's data plate for exact measurements and weights.

This container is intended for the storage and transport of general cargo, equipment, and supplies in offshore environments. It suits use on offshore supply vessels, oil rigs, platforms, and floating production storage and offloading (FPSO) vessels, providing a secure, weather-resistant way to move essential materials to and from marine installations.

Package Includes

• 1 x 20ft DNV Offshore-Rated Container
• 1 x Set of DNV-Certified Lifting Slings
