20ft Flat Rack Container – Cargo-Worthy, Lashing Rings
$3,200
SKU: CCH-10159
Available to order — we confirm availability and your delivery window before dispatch
This 20-foot flat rack container is a steel base frame fitted with collapsible end walls for moving oversized cargo. Made from COR-TEN steel, it suits intermodal freight transport, heavy equipment shipping and over-dimensional loads. Key Features
- Nationwide shipping on all orders.
- 30-day returns — see how returns work.
- Orders are processed once payment has cleared.
Payment Methods We Accept
This 20-foot flat rack container is designed to carry cargo that won't fit inside standard enclosed containers. It is built around a heavy-duty steel base frame with collapsible end walls at each end. With the end walls folded down, several flat racks can be stacked together for return transport.
The open sides and top take oversized machinery, vehicles, timber, pipes and construction materials. Lashing rings are built into the base frame and end walls to secure cargo in transit, and a corner casting at each corner supports lifting, stacking and securement aboard vessels, chassis or rail cars.
The unit is rated cargo-worthy, confirming it meets the structural requirements for intermodal freight transport. Its base frame uses steel cross members and a flush-mounted hardwood floor that handles wheeled and tracked equipment, while the COR-TEN steel end walls lock upright for transit.
Key Features
- External Length: 20 ft (6.06 m)
- External Width: 8 ft (2.44 m)
- End Wall Height (erected): 6 ft 8 in (2.03 m)
- Base Frame Height: 2 ft 2 in (0.66 m)
- Internal Length: 19 ft 5 in (5.92 m)
- Internal Width: 7 ft 8 in (2.34 m)
- Maximum Payload: Approximately 31,000 kg (68,300 lbs)
- Tare Weight: Approximately 2,800 kg (6,200 lbs)
- Number of Lashing Rings: 16+ (base and end walls)
- Material: COR-TEN steel
- Floor Material: Hardwood
- End Wall Configuration: Collapsible, locking
- Corner Castings: ISO standard
- Classification: Cargo-worthy
Intended for intermodal freight transport and ground-level applications, this unit handles oversized machinery and equipment shipping, construction material transport, timber and pipe shipments, vehicle and heavy equipment transport, project cargo and industrial work, and storage of non-containerizable goods.
Package Includes
- 1 x 20-foot flat rack shipping container
- 2 x collapsible end walls with locking mechanisms
When a 20ft Flat Rack Container for Sale Is the Only Thing That Works
Some loads simply will not go through a set of container doors. A 20ft flat rack container for sale solves that by removing the walls and roof entirely, leaving a heavy steel base frame with collapsible ends that you load from the side, the top, or both. Machinery on skids, boat hulls, transformers, bundled pipe — anything wider or taller than a door opening becomes shippable.
This unit is graded cargo-worthy, which for a flat rack matters more than it does for a dry box. The deck and frame carry the entire load, so the assessment focuses on the base structure, lashing points, and corner castings. When the end walls fold flat, several racks nest together for return movement, which is why carriers keep them in rotation instead of shipping air.
Specifications at a Glance
- Condition grade: Used, cargo-worthy — assessed sound for intermodal transport
- External footprint: 20' long × 8' wide, ISO-compatible
- Deck: hardwood floor over steel crossmembers, flush for wheeled and tracked equipment
- End walls: collapsible and locking, fold flat for nesting
- Securing points: lashing rings built into the base frame and end walls
- Construction: COR-TEN weathering steel with ISO corner castings
- Loading: open on both sides and the top, no door opening restriction
- Delivery: flat $500 to any US state, scheduled once your order is confirmed
Oversized Cargo That Suits a Flat Rack Shipping Container
Anything you would otherwise have to disassemble to fit inside a box is a candidate for a rack.
- Construction plant, attachments, and tracked equipment driven or craned onto the deck
- Steel sections, pipe bundles, and long timber that exceed door width
- Industrial machinery, tanks, and transformers shipped as a single piece
- Vehicles, boats, and specialty chassis moved without enclosure
- Precast and stone products loaded from above by crane
Loading, Lashing, and What to Arrange Before Delivery
A flat rack is only as safe as its securing plan. Work out lashing angles, chocking, and weight distribution before the cargo goes on, and keep the load centered over the frame rather than concentrated at one end. Most racks are loaded by crane or forklift, so your site needs the headroom and hardstanding for that equipment, not just space for the rack itself.
If the cargo is tall rather than wide, an open top 20ft container gives you crane access with walls still in place. For longer loads, step up to the 40ft flat rack. You can see related equipment across our specialized container range and the 20-foot category. If you are unsure which format suits your load, talk it through with our team before ordering.
Frequently Asked Questions
Can a flat rack be used for storage instead of shipping?
It can, but it is rarely the right choice. With no walls or roof there is no weather protection and no security, so anything left on the deck is exposed. Racks earn their keep in transport and as a heavy-duty loading platform. For stationary storage, an enclosed dry container costs less and protects more.
Do the end walls have to be raised?
No. They fold flat when the cargo does not need them or when the rack itself is being moved empty, and they lock upright when you want end restraint for the load. Whether they stay up depends on your cargo and your securing plan, which should be agreed with whoever is handling the shipment.
How is a flat rack delivered to my site?
It travels on a trailer like any other 20-foot unit and is normally offloaded by crane or forklift rather than tilted off, since there is no enclosed shell to slide. Make sure you have firm ground, clear overhead access, and suitable lifting equipment on site, and tell us about access constraints when you place the order.
| SKU | CCH-10159 |
| Condition | Used (Cargo Worthy) |
| Categories | 20ft Containers, Flat Pack Units, Specialized Containers |
| Availability | Available to order — nationwide delivery |
We deliver to all 50 states for a flat $500 per order — the same price regardless of container size, quantity, or distance. That fee is added in your cart and at checkout, and there is no distance or size surcharge. A tilt-bed truck slides the container to ground level and places it as close as safely possible to where you want it.
Need help preparing your site or choosing the right delivery method? Call us at (440) 379-3940 or request a quote.
